CUSTOM EXPANDABLE Mass Airflow Test Machine
Custom nozzles available in any size! Available with optional airflow straighteners based on ASME MFC-7M specifications. These machines are expandable and can be created in single, double, triple nozzle configurations. As your airflow needs increase, the system can be expanded with additional nozzles in any size!
If budget is a concern and your flow ranges are limited now but may grow in the future, please contact us about our expandable 611+ machines. Our expandable modular flow machines can grow with your needs.
Flow Capabilities
- 0.000119 to 1.231 Pounds per Second
- 0.000189 to 1.956 Flow Parameter
Specifications
- NIST Traceable Airflow Measurement
- Mass Flow Measurement Accurate to +/- 1% accuracy with standard gauges, optional 0.5% accuracy with higher accuracy gauges
- GE, CFM, Pratt & Whitney, ABB, Honeywell, Siemens, Rolls-Royce, and Solar Parts Testing
- 15 to 45 Seconds per Part Test
- Fully Automatic Operation and Pressurization
- Sonic Nozzles (9) – with Automatic Size Selection
- Single or Dual Sonic Flow Nozzle Operation
- Part Test Profiles Available for Hundreds of Engine Parts
- English and SI Units
- Industrial Intel Computer
- Dual LED displays on ergonomically friendly Ergotron arms
- Quality Control Report, Label and Data Acquisition File
- Included In-house or Online Operator Training, Testing and Certification
- Included One Year Warranty on Parts and Labor
- Can also flow small Effective Flow Area measurements
- Real production oriented software designed for Airflow Measurement
Options
- Additional Flow Ports B & E
- Low Pressure P3 0-2 PSIG (0-55 “H2O)
- Bar Code Reader
- Label Printer and Bar Code Software Output
- Printer
- Enhanced Report Software (8.5 x 11 or A4)
- Wireless Network Option
- Dew point Meter w/Warning
- Data Conversion
- Low Pressure Warning
- Lockout Box
- Side Table (Left or Right)
- Statistical Software
- Networked Results Server
- Fixture Control Language, Send Commands to Tooling
- Inset LCD Display (Instead of external mount)
- External Verification Master Nozzles
- Air Dryer Systems
- 300 – 500 Gal. Accumulator tanks sold in pairs
- Lifetime annual calibration packages
Need more accuracy? CCDI can offer Digital Transducers.
