Effective Flow Area Fixtures
CCDI creates vane and vane segment EFA fixtures for Pratt & Whitney Canada's PT6 engine. All parts for each variation of the PT6 engine
All EFA airflow fixtures are compatible with the Fleming AF36 airflow rig.
Contact us to let us know your challenge or problem and we'll deliver you a solution.
Custom Fixtures:
- Airflow Test Fixtures for Vane Segments
- Airflow Test Fixtures for turbine engine blades and vanes
- Airflow Test Fixtures for combustors
- Built for Mass Airflow testing of any turbine blade, vane, or shroud for ALL engines by Specification
- May be pneumatically operated to increase productivity
- Custom molded gaskets and o-rings
- Single hole to multi airflow testing capability
- Send us your engine component or airflow requirements and we'll be pleased to provide you with a competitive quote. If we do not have the part in house, we may request for you to send it to us to ensure perfection the first time around.
- 2D and 3D Fixture drawings are also available for additional costs.
Past fixtures we've created:
Honeywell
- 3060840 - 1 Dual Vane Segment
- 3091795 - 2 Dual Vane Segement
Rolls Royce
- Rolls Royce - 501K Dual Vane Segment
- Rolls Royce - 05-23075776 Combustor
- Rolls Royce - T56-501 Stage 1
- Rolls Royce - 250 - Diffusers (All)
Pratt & Whitney
- P&W - F100
- P&W Canada - PT6 Rotor Vane Ring
- P&W Canada - PT6 Stator
